● Intel Core i5-1235U/i7-1255U processor
● Ubuntu OS and 16GB RAM＋128GB storage
● 10.1 inch IPS Full HD screen with 10-point capacitive touch
● 2.4G/5.8G Dual band WIFI 6
● High speed 4G LTE
● BT 5.1 fast transmission
● Choose 1 from 4 modules (2D scan engine, RJ45 Gigabit Ethernet, DB9 and USB2.0 )
● Support GPS, Glonass, Optional Beidou
● Equipped with multiple accessories, like docking charger, hand-strap, vehicle mount, car charge, carry handle
● IP65 Waterproof and Dustproof, Anti-Static
● Vibration & 1.22m drop resistant
● MIL-STD-810G certified
Ubuntu
IP65
GPS
Dual-battery
Bluetooth
2D
NFC
4G
WIFI
Camera
* All technical data, specification and performance figures subject to change without notice.
| Tech Spec | |
| Product Form | 10.1 inch Rugged Tablet |
| Material | ABS+PC |
| Dimension | 289.9*196.7*27.4mm |
| Weight | 1230g |
| Product Color | Black |
| CPU | i5-1235U, TDP15W, 2P-Cores, 10E-Cores, 12threads, 0.9GHz~4.4GHz Optional: i7-1255U, TDP15W, 2P-Cores, 10E-Cores, 12threads, 1.2GHz~4.7GHz |
| GPU | Intel® Iris® Xe Graphics eligible |
| Memory | RAM 16GB DDR4L ROM 128GB SSD |
| Operating System | Ubuntu22.04.4 |
| Display | Type: LCD Size: 10.1 inch 16:10 Resolution: 1200*1920 Brightness: 700cd/㎡ |
| Touch Pannel | 10 points capacity TP, G+F+F, Hardness over 7H, Scratch resistant, Support stylus |
| Camera | Front 2.0MP (USB) Rear 8.0MP (USB) |
| Buttons | Power *1 Volume Key + *1 Volume Key - *1 Windows Home *1 F Key *1 (Barcode Scanning, Customizable without barcode) |
| Speaker | 8Ω/1W Waterproof Speaker *1 |
| Microphone | Waterproof microphone 4618, specification: - 44dB±3DB |
| Senssors | G_sensor |
| Fan | IPX5 Fan *1 |
| RTC Battery | 3V 210mAH Continuous discharge current: 0.2mA Diameter: Ø20.0mm Max Thickness: 3H.2mm |
| Small Battery | Build in Lithium-ion polymer battery, Non-removable 7.4V/700mAh |
| Big Battery | Removable Li-polyment Battery 7.4V/5000mAh 4.5h ( 50% volume sounds, 50% screen brightness, 1080P HD video display by default ) |
| WIFI | Wi-Fi 6 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax Dual frequency 2.4G+5.8G WIFI |
| Bluetooth | BT5.1 (BLE) class1 Transmited distance：10m |
| 4G | MeiG 750 LTE-FDD: B1/3/5/7/8/20 LTE-TDD: B40 WCDMA: B1/5/8 GSM: 900/1800 China (Unicom, mobile support is poor, only B8 supports without TDD band) Europe, Middle East, Africa, Taiwan, Japan Optional: MeiG North America and South America modules |
| GPS | U-blox M7N, Support: GPS, glonass Optional: U-blox M8Q, Support: GPS, Beidou, glonass |
| I/O Interface | USB3.0 *1 |
| Type C (Full function/HDMI/Charging) *1 | |
| ∮3.5mm Standard earjack *1 | |
| HDMI 2.1a mini *1 | |
| SIM card *1 | |
| TF card *1，Max: 128GB | |
| DC 19V 3.42A jack *1 | |
| 12PIN Pogo Pin (USB/Docking charging) *1 | |
| Adapter | AC100V ~ 240V, 19V 3.42A/65W Output USA Standard CE approval Optional: EU UK |
| Rugged Features | MIL-STD-810G: 1.22m drop |
| Working temperature: -20 °C to 60 °C | |
| Storage temperature: -30 °C to 70 °C | |
| Electrostatic discharge: ± 8kV contact discharge, ± 15kV air discharge | |
| Humidity: 95% Non-Condensing | |
| Certification | IP65 |
| CE | |
| CCC | |
| MIL-STD-810G | |
| Battery: UN3803, MSDS, IEC62133, aviation report, marine report | |
Various modules and accessories can be selected to meet customers' application in various industries.
