● Equipped with Quad-core Intel JASPER LAKE N5100 processor and running Ubuntu OS, up to 4GB + 64GB high-speed capacity.
● 10.1-inch screen, 700 cd/m² high brightness display, multiple-point touch panel and customized keys , ensuring outdoor worker visibility.
● 4G LTE, dual-band Wi-Fi and Bluetooth 5.0 connectivity. Multi-satellite systems of GPS/Glonass/Beidou, with available vehicle mushroom antenna for real-time tracking to your vehicle and asset management.
● With aviation plug charging interface, switchable for cigarette lighter interface or Φ5.5 power port, and the external 9V-36V DC wide voltage module is optional.
● Supports the battery-free mode, another optional 7.4V/1000mAh capacity battery.
● Available multiple navigation plug interfaces, and also supports USB/DB9/LAN/CAN and other interface extensions.
● Two bracket mounting methods, VESA and RAM are suitable for almost any vehicle-mounted workplaces.
● IP65 dustproof and waterproof, morphed to endure outdoor applications prone with shock, vibration and extreme temperature.
Ubuntu-20.4.5
IP65
GPS
BT5.0 (BLE)
4G
WIFI
Battery ● Equipped with Quad-core Intel JASPER LAKE N5100 processor and running Ubuntu OS, up to 4GB + 64GB high-speed capacity.
● 10.1-inch screen, 700 cd/m² high brightness display, multiple-point touch panel and customized keys , ensuring outdoor worker visibility.
● 4G LTE, dual-band Wi-Fi and Bluetooth 5.0 connectivity. Multi-satellite systems of GPS/Glonass/Beidou, with available vehicle mushroom antenna for real-time tracking to your vehicle and asset management.
● With aviation plug charging interface, switchable for cigarette lighter interface or Φ5.5 power port, and the external 9V-36V DC wide voltage module is optional.
● Supports the battery-free mode, another optional 7.4V/1000mAh capacity battery.
● Available multiple navigation plug interfaces, and also supports USB/DB9/LAN/CAN and other interface extensions.
● Two bracket mounting methods, VESA and RAM are suitable for almost any vehicle-mounted workplaces.
● IP65 dustproof and waterproof, morphed to endure outdoor applications prone with shock, vibration and extreme temperature.
| Tech Spec | |
| Product Form | 10.1 inch Vehicle PC |
| Material | PC+ABS+10%GF |
| Dimension | 264.5*184.1*23.0 mm |
| Weight | 834g |
| Product Color | Black |
| CPU | Intel JASPER LAKE N5100 Max 2.8GHz |
| GPU | Intel® HD Graphics Gen 11 LP |
| Memory | RAM 4GB LPDDR3 ROM 64GB EMMC （Folllow-up update to 8GB+128GB） |
| Operating System | Ubuntu22.04.4 |
| Display | Type: HD Size: 10.1 inch 16:10 Resolution: 800*1280 IPS Brightness: 700cd/㎡ （Folllow-up upgrade to 1000cd/㎡） |
| Touch Pannel | 5-point tempered glass capacitive screen G+G, Hardness above 8H |
| Buttons | Power *1 Volume Adjustment Key (+) *1 (F1 Key) Volume Adjustment Key (-) *1 (F2 Key) Customizable *1 (F3 Key) Customizable *1 (F3 Key) |
| Indicator Light | 1. Power-on indicator (red when DC is powered on) 2. Power indicator (blue when starting) 3. Low battery indicator (When there is a battery, the red light flashes when the battery is low, and it is not lit in normal state). |
| Speaker | 1.5W Single Horn |
| Microphone | Single MIC |
| RTC | Built in 2032 RTC dry battery |
| Battery (Tablet) | Optional, Built in polymer lithium ion battery 1000mAh/7.4V |
| WIFI | WIFI 802.11(a/b/g/n/ac) Dual frequency 2.4G+5.8G |
| Bluetooth | BT5.0 (BLE) class1 Transmited distance: 10m |
| 4G | Optional, South America or North America module, LTE FDD: B1/B3/B5/B7/B8/B20 LTE-TDD B40 WCDMA: B1/B5/B8 GSM: 900/1800 |
| GPS | Built in, Ublox 7 supports GPS, GLONASS Optional, Huada Beidou/Ublox M8Q |
| NFC | Optional, NXP300 NXP NFC 13.56MHz supports 14,443A/14,443B/15,693/18,092/mobile protocol under ISO/IEC. Card reading distance: 4cm |
| Rugged Features | Working temperature: -20 °C to 60 °C |
| Storage temperature: -30 °C to 70 °C | |
| ±8kV contact discharge, ±15kV air discharge | |
| Humidity: 95% Non-Condensing | |
| Certification | IP65 |
| CE | |
| CCC | |
| FCC | |
* Please be aware all technical data, specification and performance figures subject to change without notice.
Various modules and accessories can be selected to meet customers' application in various industries.
Various modules and accessories can be selected to meet customers' application in various industries.
